Servo motor high speed barrier gate

Servo motor barrier gate is a product in order to achieve accurate control, position accuracy, smooth operation and high-speed operation requirements, It have equipped with the high voltage ac servo motor + precision planetary reducer, by four bar linkage of the brake lever within 90 ° cycle, at the same time through the photoelectric + coder joint positioning, precision control of the barrier gate, so precision of the arm lever Angle is 0.01 °.
Servo motor barrier gate is more efficiency compared with other types of products , its comprehensive efficiency can reach above 85%, transmission of torque is greatly increased at the same time, also bring product calorific value will be greatly reduced, thus will bring better high temperature adaptability of product.

Characteristics

1. Servo gate is suitable for all existing barrier gate design.
2. The servo motor barrier gate has the self-learning function, that is, the gate can pass through the initial stage according to the load carried by it After learning, it can automatically plan according to the learning parameters (including inertia, damping, etc.)
The minimum running time of the gate under this load and the minimum running time as the default Between, unless it is set to a parameter greater than that time;
In addition to initializing self-learning, you can also self-learn during the run, depending on the resistance of the load in the run
Automatic adjustment of operating parameters;For example: after a night of freezing in the northern winter, the damping increases, but it still remains Can self-learn to run;
3. Strong speed range: from 0.3 to 6 seconds (servo) for all operating time range;
4. The servo gate adopts servo motor + planetary reducer, with higher transmission efficiency and better precision;

Configuration

1. Equipped with servo control movement;
2. Built-in servo drive;
3, with a traffic light indication (teng xiang);
4. Configurable led light;
5. Configurable ground sensing radar;
6. Equipped with alarm prompt device (including disassembly of the opening door and brake bar);
7. With its own network interface, it can directly link to the cloud;
8. Bluetooth setting parameters can be configured and the switch can be controlled.

Features

1. The servo motor adopts three closed-loop control, so as to maintain high operating efficiency in the operation of the gate
Open/close time can reach 0.3 seconds (carbon fiber arm), superior to all competitors;
2, the unique left and right open synchronization function, to ensure that the synchronous Angle of the switch opening machine is less than 3°;
3, modular design, clean process, more beautiful products, higher reliability;
4. The control system adopts TCP/IP communication, with remote diagnosis and upgrade function to facilitate product maintenance;
5, the unique torque detection function, when the arm is subjected to resistance, immediately stop operation, protection device
Standby and accessible objects;

6. The servo control adopts photoelectric and coding co-positioning, so the positioning is more accurate, with the position accuracy of 0.01°;
7, can integrate with bollard, can achieve stronger control;
8. The bluetooth module can be configured to set the parameters of the mobile device and realize the bluetooth switch opening;
9, can be configured with traffic lights and led lights, to achieve a variety of choices;
10. The unique load release design ensures the energy release during the motor braking;
11. All-directional product test design, which can detect abnormalities such as opening of the box door and disassembly of the brake bar;
12. The product is equipped with the functions of starting up and running self-inspection to record the running status of the product in real time;
13. With motor heating function, it is better used in low-temperature areas;
14. Automatic lever lifting function for power failure.

Application

Parking lot,Hotel,Community,Factory,Bus station.

.
